Multipurpose PVC Hose (Alfaflex Filclair AL)

Call 022-42826 for price and availability

Flexible food-grade reinforced PVC hose from Technix, suitable for industrial gases, liquids, and foodstuffs. Vacuum-rated up to Ø25 mm. Temperature: -15°C to +60°C. Certified IANESCO RE 11/10484.

Description

The Alfaflex Filclair AL is a flexible, polyvalent reinforced PVC hose with food-grade quality. Suitable for a wide range of media including industrial gases, liquids, and foodstuffs. Can be used under vacuum up to Ø25 mm. Temperature range: -15°C to +60°C. Now from Technix Rubber and Plastic in Mallow.

Construction:

Tube: Transparent PVC, food-grade quality
Reinforcement: High tensile textile thread
Cover: Transparent PVC, food-grade quality

Certification: IANESCO RE 11/10484 dated 10/08/2011

Attention: Approved for food simulants A, B, C and D1. Formally discouraged for hydrocarbons and derivatives. Prohibited for fatty products (e.g. vegetable oils).

Applications: Compressed air supply, industrial gases and liquids, light chemical products.
Assembly: All types of industrial couplings; hose-clamps.

Additional information

Weight	N/A
Coil Length (m)	25, 50
Bending Radius (mm)	40, 55, 60, 65, 75, 80, 85, 90, 100, 110, 125, 130, 150, 160, 180, 185, 220, 250, 280, 350, 420
Burst Pressure (bar)	25, 27, 32, 38, 50
Working Pressure (bar)	8, 10, 12, 15
